Specifications
Image Sensor
-
Sensor – 1/2.3-type CMOS
-
Filter – RGB Primary Colour Filter
-
Total Pixels – Approx. 21.14MP
-
Effective Pixels per Sensor – Approx. 8.29 MP (3840 x 2160)
-
Subject Illumination Range – Approx. 0.3 lx to 100,000 lx
-
Minimum Illumination (PAL) – P (Program AE) Mode: Approx. 4.2 lx (shutter speed 1/25 sec with auto slow shutter On)Low Light Mode: Approx. 0.3 lx (shutter speed 1/2 sec.)
Image Processor
-
Type – DIGIC DV 6
-
Colour Sampling – YCC 4:2:0 8bit
Lens
-
Zoom Ratio – 20x Optical
-
Focal Length (35mm Equivalent) – Approx. 29.3 – 601mm Standard IS/IS Off
-
Minimum Focus Distance – 1 cm at wide end, 60 cm across entire zooming range
-
Max. Aperture – f/1.8 – 2.8 (AV Priority and Manual Modes)
-
Aperture Blades – 8 blades
-
Filter Diameter – 58mm
-
Image Stabilization System -Optical system (lens shift) + electronic stabilization Dynamic, Standard, Powered IS, Off
-
ND Filter – Built-in gradation filter (Auto or Off)
-
Zoom Control – Zoom rockers on body and handle;Selectable manual zoom/focus ring on lens;
Selectable High Speed and Soft Zoom modes available. -
Zoom Speed -Variable (body rocker only) or Constant speed (body and handle rocker; Fast/Normal/Slow, 16 speed level settings in each)
-
Focus Control – MANUAL: Lens ring and touchscreen point selection (Magnify and Peaking assist functions), Focus Preset.AUTOFOCUS: Touchscreen AF point selection, Face Detection and Tracking, Touch and Track, Face Only AF. (Instant AF, Medium AF, Normal AF)
-
Focus System – Hybrid AF (High Speed/Medium speed). Uses combination of TTL-video signal detection system and external phase difference metering system.Normal AF. TTL, Contrast based AF
-
Iris Control – Touchscreen, Auto
-
Digital Zoom/Teleconverter – 20x digital zoom (400x with optical zoom) and 40x digital zoom (800x with optical zoom) are available. Digital zoom not available in AUTO mode. 2x Digital Teleconverter
Recording
-
Video Storage Media – SD/SDHC/SDXC card (2 card slots)
-
Recording Time – 150Mbps: 55 mins / 35Mbps: 240 mins / 17Mbps: 495 mins
-
Recording File System – FAT32/exFAT
-
Internal Recording Format (PAL) – XF-AVC: 3840 x 2160 / 25.00P (160 Mbps) / 1920 x 1080 / 50.00P, 50.00i, 25.00P (45 Mbps)MP4: 3840 x 2160 / 25.00P(150 Mbps) / 1920 x 1080 / 50.00P, 25.00P (35, 17 Mbps)
-
External Recording Output – HDMI output (When Shooting)/UHD recording mode/ Full HD recording mode / SDI output (When Shooting)/ UHD recording mode /Full HD recording mode
-
Slow/Fast Motion (PAL) – 3840 x 2160 / 25.00P: x2, x4, x10, x20, x60, x120, x600, x1200,1920 x 1080 / 50.00P: x2, x4, x10, x20, x60, x120, x600, x1200,1920 x 1080 / 25.00P: x0.5
-
Pre-Record Function – Yes. 3 seconds
-
Still Photos – JPEG up to 3840×2160 (Still image resolution is dependent on the video resolution)
-
Photo Storage Media – SD Card
System
-
Display Type – Capacitive LCD touch panel
-
Size – 3.5-inch (8.8 cm) on the diagonal, Approx. 2,760,000 dots (1280 x RGB x 720)
-
Wave Form Monitor – No
-
Focus Assist – Peaking / Magnify
-
Peaking – Selectable Peaking Colour: Red / Blue / Yellow
-
Zebra – 70% or 100% reference level
-
Markers – Grid (white/grey), Level (white/grey), 4:3 (white/grey)
EVF
-
Size – 0.36-inch (0.92 cm on the diagonal), Approx. 1,770,000 dots (1024 x RGB x 576)
-
Correction Lens – +2.0 to -5.5 dioptre
Inputs / Outputs
-
Audio Input – XLR 3-pin jack (x2) with 48V phantom power, Line and Mic options on detachable handle,3.5mm microphone input jack (Supply Voltage 2.4V DC)
Built-in Mic -
Headphone Output – 3.5mm stereo mini jack
-
HDMI Output – HDMITM mini connector
-
USB – Type-CHi-Speed USB (USB 2.0) equivalent. Point-to-point class and UVC supported.
-
SDI Output – 3G-SDI
-
Time Code – Rec Run / Free Run
-
Genlock – No
-
LAN – No
-
AV Terminal – No
-
DC Input – USB-C
-
Remote Control Terminal – 2.5mm mini jack
Miscellaneous
-
Tally Lamp – Yes, in detachable Handle Unit
-
Colour Bars (PAL) – Yes. SMPTE, ARIB or EBU, with 1KHz Tone
-
Accessory Shoe – Yes (cold shoe)
-
Assignable Buttons – 5 assignable Buttons
-
Custom Dial – Iris/Shutter/Gain, AGC Limit, Exposure Compensation, Off
Exposure
-
Exposure Metering – Center-weighted average metering/AUTO, P, Av, Tv, Portrait, Sports, Low Light and IR modes / Segment evaluative metering / Night Scene, Snow, Beach, Sunset, Spotlight modes / No metering in Fireworks mode: Exposure constant
-
Exposure Compensation – Highlight AE, Normal, Exposure lock, Auto backlight compensation.
-
Exposure Lock – Yes.
-
Auto ISO / Auto Gain Control Setting – Auto / Manual
-
Auto Gain Control Limit – 0 – 23dB (1dB increments)
Shutter Speed
-
Control Modes – Auto, P, Tv, Manual
-
Shutter Speed (PAL) – 1/6 – 1/2000 sec(1/2 – 1/500 sec in Low Light mode)
-
Slow Shutter (SLS) – 50.00P:Auto slow shutter On: 1/25 to 1/500 sec.
Auto slow shutter Off: 1/50 to 1/500 sec. 25.00P:
Auto slow shutter On: 1/12.5* to 1/500 sec. (*Display is 1/12)
Auto slow shutter Off: 1/25 to 1/500 sec. -
Clear Scan (PAL) – No
Streaming, Wi-Fi, & GPS Specifications
-
Wi-Fi – No
-
GPS Information (Optional Accessory) – Location (Latitude/Longitude/Altitude), Coordinated Universal Time (UTC), Satellite reception.(requires the optional GPS Receiver GP-E2)
White Balance
-
Auto – Yes
-
Preset – Daylight (Approx. 5,600K), Tungsten (Approx. 3,200K)
-
Manual Setting – Colour Temperature range: 2,000–15,000KDefault value for Set 1 and Set 2: 5,600K
Shooting Modes
-
Program AE – AUTO mode, M (Manual) mode ,P (program AE), Tv (shutter-priority AE), Av (aperture-priority AE), M (manual exposure), SCN (Portrait, Sports, Night Scene, Snow, Beach, Sunset, Low Light, Spotlight, Fireworks) IR mode
-
Custom Picture Menu – C1: Normal (BT.709 Normal / BT.709)C2 to C6: USER02 to USER06
-
Look Settings – Standard(Adjustment: Sharpness, Contrast, Colour Depth)
-
Colour Matrix Settings – Neutral: accurate colour reproductionVideo: Higher contrast colour reproduction
-
Infrared Shooting Mode – Yes (green or white)
-
Built-in IR Lamp – Yes, in detachable Handle Unit.Wavelength: 850nm (near-Infrared)
Audio
-
Recording Format – MPEG-2 AAC-LC (16-bit 2ch) / LPCM (16-bit 4ch)
-
Audio Control – Manual/AutoIndependent 2ch Line/Mic/Mic+48V input;/ Independent level control per channel (-∞ to +18 dB);/Independent audio limiters (2 ch);/Input mic trimming
-
Reference Tone – 1KHz, -12dB / -18dB / -20dB / Off
-
Microphone Attenuation – On/Off (20dB)
-
Microphone Level Meter – Yes
Accessories
-
Supplied – Lens hood with barrier, Mic holder unit, Handle Unit, Battery Pack BP-820, USB Power Adapter PD-E1, AC Cable
-
Optionals – Canon Battery Pack BP-820/BP-828, Canon Battery Charger CG-800E/CG-800, Canon HDMI cable HTC-100/HTC-100S, Canon Tele Converter TL-H58, Canon Wide Attachment WA-H58, Canon Shoulder Strap SS-600/SS-650, Wrist Strap WS-20, Canon PROTECT Filter 58mm, Canon ND4-L Filter 58mm, Canon ND8-L Filter 58mm, Canon GPS Receiver GP-E2, Canon Remote Controller RC-V100, Canon Battery Video Light VL-10Li/VL-10LiII, Canon Battery Pack BP-900 series (for VL-10Li/VL-10LiII), Canon Compact Power Adapter CA-910/920/930 (for charging BP-900 series), Canon Interface Cable IFC-300PCU/S / IFC-400PCU
Power Source
-
Power Supply (Battery) – Canon Battery Pack BP-820 (supplied), BP-828 (optional)
-
Power Consumption – UHD: MP4, 150Mbps 25.00P : Approx. 4.5W /XF-AVC,160Mbps 25.00P : Approx 4.5WFull HD: MP4, 35Mbps 50.00P : Approx. 4.6W/XF-AVC, 45Mbps 50.00P : Approx. 4.6W
-
Recording Time – UHDMP4: 150Mbps/25.00p: Max. 165 mins (BP-820), typical 95 mins /Max. 240 Mins, typical 140 mins ( Optional BP-828)/ XF-AVC: 160Mbps/25.00P: Max. 160 mins (BP- 820), typical 95 mins./Max. 230 mins, typical 145 mins (Optional BP-828)
Physical Specifications
-
Dimensions – Approx. 109 x 84 x 182 mm (main body only)Approx. 131 x 180 x 231 mm (Including lens hood, BP-820, mic holder unit, and handle unit)
-
Weight (Body Only) – Approx. 750g
-
Weight (Accessories) – Approx.1140g
-
Operating Temperature Range – 0ºC to +40ºC, 85% relative humidity
